NZXT H7 Elite Mid-Tower RGB Case Black

KEY SPECS

• Motherboard Support: Mini-ITX, Micro-ATX, ATX
• Enclosure Type: Mid-Tower
• Case Material: SGCC Steel, Ultra-clear Tempered Glass, Dark Tinted Tempered Glass (Black only)

DIMENSIONS

• Height:505mm (With Feet)
• Width:230mm
• Depth:480mm
• Weight:11.36 kg

COMPATIBILITY & CLEARANCE

• Max CPU Cooler Clearance: Up to 185mm
• Max GPU Clearance: Up to 400mm
• Front Radiator Clearance:60mm
• Top Radiator Clearance:30mm
• Cable Management:18-22mm

FRONT I/O PORTS

• USB 3.2 Gen 1 Type-A:2
• USB 3.2 Gen 2 Type-C:1
• Headset Audio Jack:1
• RGB CONTROLLER
• NZXT RGB Connector:3 (Supports up to 120 LEDs)

EXPANSION SLOTS

• Standard:7
• Vertical:0

DRIVE BAYS

• 2.5":4+2
• 3.5":2

FAN SUPPORT

• Front:3 x 120mm / 3 x 140mm
• Top:3 x 120mm / 2 x 140mm
• Rear:1 x 120mm / 1 x 140mm
• Filters: All Air Intakes

RADIATOR SUPPORT

• Front: Up to 360mm with Push/Pull
• Top: Up to 360mm
• Rear: Up to 140mm

FAN SPECS

• Model: F140Q (Case Version)
• Speed:1200 ± 240RPM
• Airflow:99.56 CFM
• Static Pressure:1.14 mm-H2O
• Noise:24.18 dBA
• Fan Connector:3-pin

FAN SPECS

• Model:F140 RGB Core Fan
• Speed:500-1,500 ± 150 RPM
• Airflow:90.79 CFM
• Static Pressure:3.22 mm H2O
• Noise:34.48 dBA
• Fan Connector:4-pin PWM
